| Place of Origin: | U.K. |
| Brand Name: | Siemens |
| Certification: | COO & COC |
| Model Number: | 6ES7138-4DA04-0AB0 |
6ES7138-4DA04-0AB0 Siemens SIMATIC ET200S High-Speed Counter Module
The Siemens 6ES7138-4DA04-0AB0 is a SIMATIC ET200S high-speed counter module designed for precise counting, frequency measurement, and position detection in industrial automation systems. As part of the Siemens ET200S distributed I/O platform, this electronic module provides high-speed pulse processing up to 100 kHz, making it ideal for encoder applications, motion monitoring, speed measurement, and industrial process control.
The module supports advanced operating modes including counting, measuring, and high-resolution cycle duration measurement with clock synchronization. The 6ES7138-4DA04-0AB0 is widely used in factory automation, conveyor systems, packaging machinery, motion control systems, and industrial production lines requiring accurate high-speed signal processing.
With compact 15 mm installation width, stable industrial performance, and seamless integration into Siemens ET200S distributed I/O systems, this counter module delivers reliable operation in demanding industrial environments.
Product Overview: Siemens 6ES7138-4DA04-0AB0
| Product Name | Siemens SIMATIC ET200S Counter Module |
|---|---|
| Part Number | 6ES7138-4DA04-0AB0 |
| Product Family | SIMATIC ET200S |
| Module Type | High-Speed Counter Module |
| Counter Channels | 1 Channel |
| Input Voltage | 24 V DC |
| Maximum Input Frequency | 100 kHz |
| Counter Resolution | 32-bit |
| Operating Modes | Count, Measure, Cycle Duration Measurement |
| Encoder Support | Incremental Encoder, 24 V Initiator |
| Input Delay | 2.5 µs (200 kHz) / 25 µs (20 kHz) |
| Encoder Supply | 24 V DC, max. 500 mA |
| Digital Inputs | 1 |
| Digital Outputs | 1 |
| Installation Width | 15 mm |
| Power Consumption | Approx. 1 W |
| Communication | PROFIBUS / PROFINET via ET200S Interface |
| Protection Class | IP20 |
| Operating Temperature | 0°C to +60°C |
| Dimensions | 15 × 81 × 52 mm |
| Weight | Approx. 40 g |
In stock | Fast delivery | Global shipping
Product picture
Applications
The Siemens 6ES7138-4DA04-0AB0 counter module is widely used in:
It is ideal for industrial applications requiring accurate high-speed counting and encoder feedback.
Product status
Available product conditions include:
| 6ES7138-4DA04-0AB0 | 6ES7138-4FA04-0AB0 |
| 6ES7138-4DA03-0AB0 | 6ES7138-4FB03-0AB0 |
| 6ES7138-4DB03-0AB0 | 6ES7138-4FC03-0AB0 |
| 6ES7138-4DC03-0AB0 | 6ES7138-4FD03-0AB0 |
| 6ES7138-4DD03-0AB0 | 6ES7138-4GA03-0AB0 |
| 6ES7138-4DE03-0AB0 | 6ES7138-4GB03-0AB0 |
| 6ES7138-4DF03-0AB0 | 6ES7138-4GC03-0AB0 |
| 6ES7138-4DG03-0AB0 | 6ES7138-4HA03-0AB0 |
| 6ES7138-4DH03-0AB0 | 6ES7138-4HB03-0AB0 |
| 6ES7138-4DL02-0AB0 | 6ES7138-4CA03-0AB0 |
FAQ
It is a Siemens ET200S high-speed counter module used for encoder signal processing, frequency measurement, and industrial counting applications.
The module supports counting frequencies up to 100 kHz.
Yes, we provide fast worldwide delivery.
