| Place of Origin: | Germany |
| Brand Name: | Siemens |
| Certification: | COC & COO |
| Model Number: | 6ES5095-8MA03 |
Siemens 6ES5095-8MA03 SIMATIC S5 S5-95U Compact Unit KompaktGeraet Version 2 Module
Overview
The Siemens 6ES5095-8MA03 is the compact CPU unit for the SIMATIC S5-95U family, engineered for reliable control of small to mid-size machines and process islands. Built on proven STEP5 technology, it combines fast cycle times with a rugged design for 24/7 industrial duty.
Technical Data
• Part Number: 6ES5095-8MA03
• Memory: 16 KB RAM for user program, 128 counters, 128 timers
• I/O Capacity: 256 digital I/O (expandable via IM 305/306)
• Interfaces: Integrated 20 mA TTY (PG/OP port) for programming and HMI
• Power Supply: 24 V DC ±20 %
• Operating Temperature: 0 … +60 °C
• Dimensions (W×H×D): 145 × 125 × 130 mm
• Certifications: CE, UL, CSA
Key Features & Benefits
• Compact all-in-one design saves panel space
• Battery-backed RAM retains program and data for ≥ 5 years without power
• Online diagnostics via PG interface reduce downtime
• Backward-compatible with existing S5-95U racks and I/O modules
Typical Applications
• Packaging lines, textile machines, printing presses
• Water/wastewater skids
• HVAC control in commercial buildings
• Retrofit spare-part for legacy S5 installations
Product images
