ABB CDP-312R Control Panel & CABLE Code 68245508 ACS800 Assembly Kit
Product Overview
The ABB CDP-312R 68245508 is the official 4-line graphic keypad for ACS800, ACS550, and compatible ABB low-voltage drives. Featuring a back-lit LCD, intuitive menu navigation, and hot-plug capability, it simplifies commissioning, diagnostics, and parameter cloning without opening the cabinet door. Whether you need to read motor current, set speed references, or copy configurations across multiple drives, the CDP-312R delivers reliable, hands-on control right at the machine.
Key Features & Benefits
• 4-line 128 × 64 back-lit LCD – real-time speed, torque, current, alarms
• Plug-and-play RJ-45 link – hot-plug to drive while running
• Parameter cloning – copy/restore setups via internal memory
• Multi-language menu – English, Chinese, Spanish, German, French
• Password protection – secure settings against unauthorized changes
• IP20 ABS housing – panel or door mounting with gasket kit
• Compatible with ACS800, ACS550, ACS580, ACS380 families
• UL, CE, RoHS certified – global installation acceptance
Technical Specifications
Model: CDP-312R
Part No.: 68245508
Display: 4-line graphic LCD, 128 × 64 pixels, back-lit
Interface: RJ-45 (RS-232/RS-485)
Cable Length: Supplied 3 m extension; up to 15 m optional
Power: 5 V DC via drive keypad port (no external supply)
Operating Temperature: 0 °C … +50 °C
