Siemens 6SL3220-2YE34-0UP0 SINAMICS G120X infrastructure converter with Basic Operator Panel

Siemens 6SL3220-2YE34-0UP0 SINAMICS G120X infrastructure converter with Basic Operator Panel

Product Highlights
• Model: 6SL3220-2YE34-0UP0
• Rated power: 30 kW (110% overload for 60 s, 100% load for 240 s)
• Input voltage: Three-phase 380–480 V AC (tolerance +10% / –20%), 47–63 Hz
• Rated output current: 57 A (without internal filter)
• Protection rating: IP20, suitable for cabinet installation
• Communications: PROFINET, EtherNet/IP, Modbus TCP, and USS/Modbus RTU are standard; no additional options required
• Energy-saving features: ECO mode, sleep mode, and PID autotuning support efficient fan/pump control • Environmental adaptability: –20°C to +60°C operation without derating (>60°C with derating), maximum altitude 4000 m
• Certifications: CE, cULus, EAC, SEMI F47, RoHS

Typical Applications
• Energy-saving retrofits for HVAC, fans, pumps, and compressors
• Municipal water supply, sewage treatment, and HVAC systems
• Applications requiring high reliability and continuous operation, such as in the food, pharmaceutical, and chemical industries

Key Advantages
1. Plug-and-Play: Available with a built-in braking unit and EMC filter, it meets IEC 61800-3 C2/C3 requirements without external components.
2. Intelligent Cloud: Connects to MindSphere via SINAMICS Connect 300 for real-time monitoring of energy consumption and vibration, reducing preventive maintenance downtime by over 30%.
3. Modular Expansion: Supports I/O and communication expansion boards, enabling easy adaptation to future production line upgrades. 4. Quick Commissioning: A graphical wizard and mobile app (SINAMICS Smart Access Module) allow you to complete parameter configuration in less than 3 minutes.
5. Global Warranty: Backed by a 24-month Siemens warranty and 24/7 technical support from over 190 service locations worldwide.

Technical Parameters
• Cooling: Forced air cooling, low-noise fan < 55 dB(A)
• Protection: Overvoltage, undervoltage, short circuit, ground fault, motor overheating, stall protection, etc.
